8301A-16

  • Two-Piece Bronze Ball Valve, 600 WOG – 150 SWP, Threaded Ends
  • Not Intended for Use in Potable Water

Product Documents

IOMs

Spec Sheets

3D CAD Files

Product Videos

Description

Material

Bronze
ANSI/Pressure Rating

600 WOG – 150 SWP
End Connection

Threaded
Body Style

Two – Piece
Seat Material

RPTFE
Port

Full
Ball

Chrome Plated
Operator

Insulator/MS (Insulated Handle with Memory Stop)
Product Size

1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2"
Add to quote
Category:

Weights, Dimensions, and Box Quantity

Size
Unit Weight
Unit Dims.
LxWxH
Box Quantity
Box Dims.
LxWxH
1"
0
3.32 x 1.56 x 2.68
1
9.25 x 6.75 x 3.875
1"
0
3.32 x 1.56 x 4.43
1
9.25 x 6.75 x 3.875
1-1/4"
0
3.77 x 1.81 x 4.57
1
9.25 x 6.75 x 3.875
1-1/4"
0
3.77 x 1.81 x 4.57
1
9.25 x 6.75 x 3.875
1-1/2"
0
4.28 x 2.06 x 3
1
1-1/2"
0
4.28 x 2.06 x 4.75
1
2"
0
5.1 x 2.5 x 5.11
1
16 x 8.6875 x 4.9375
2"
0
5.1 x 2.5 x 5.11
1
16 x 8.6875 x 4.9375

You may also be interested in these UltraPure® "Low-Lead" or UltraPress® valves
